MIL-DTL-83513 Connectors

MIL-DTL-83513 Connectors are precision-engineered micro connectors designed to meet stringent military specifications. These connectors are widely utilized in defense and aerospace applications for their compact size, lightweight construction, and exceptional reliability under extreme conditions. Built to the M83513 specification, they ensure seamless integration into systems requiring high-performance interconnect solutions, including avionics, unmanned systems, and communications equipment.
Overview MIL-DTL-83513 Connectors
By Staff Writer Last updated: December 12th, 2024

MIL-DTL-83513 connectors, also known as Micro-D connectors, are precision-engineered components designed to meet the stringent performance demands of military, aerospace, and defense applications.

These connectors adhere to the M83513 specification, ensuring reliable operation under extreme environmental conditions, including high vibration, temperature fluctuations, and exposure to contaminants. Compact yet robust, they are essential for applications where size, weight, and durability are critical.

MIL-DTL-83513 Connector Key Features and Benefits

Micro Circular connector from Omnetics Corporation

Micro Circular connector, designed to MIL-DTL-83513 military specifications, from Omnetics Corporation.

MIL-DTL-83513 connectors are characterized by their highly compact design and ruggedized construction. Built to withstand harsh environments, these connectors deliver exceptional electrical and mechanical performance. Features include:

Miniature Form Factor

Ideal for systems with stringent size and weight constraints, such as avionics, portable electronics, and unmanned systems.

High-Density Contact Arrangements

Accommodates a range of pin counts while maintaining signal integrity and reliability.

Environmental Resistance

Engineered to endure extreme temperatures, moisture, and contaminants, ensuring long-term reliability.

Durable Materials

Typically constructed from lightweight yet sturdy aluminum or stainless steel with corrosion-resistant finishes.

Connector Variants

MIL-DTL-83513 connectors are available in several configurations to accommodate diverse application needs:

  • Solder Cup and PCB Mount: Suitable for easy integration with existing circuitry.
  • Crimp Contact Options: Offering secure wire termination for field-ready deployment.
  • Custom Configurations: Tailored solutions with unique pin arrangements, shell materials, and finishes to meet specialized requirements.

Military Applications of MIL-DTL-83513 Connectors

The versatility of MIL-DTL-83513 connectors makes them indispensable across defense and aerospace systems. Common applications include:

Avionics Systems

Supporting high-speed data and power transmission in confined spaces within aircraft.

Unmanned Systems

Enabling reliable interconnectivity in drones, ground robots, and autonomous vehicles.

Missile and Guidance Systems

Providing secure electrical connections in high-stress environments.

Ground and Naval Electronics

Ensuring efficient performance in rugged military communications and navigation equipment.

Compliance with the M83513 Specification

The MIL-DTL-83513 specification defines strict requirements for these connectors to guarantee performance consistency across military-grade applications. This standard addresses factors such as electrical properties, environmental resilience, and mechanical integrity. Connectors that meet this specification undergo rigorous testing to ensure compliance with military standards, including shock resistance, thermal cycling, and electromagnetic interference (EMI) shielding.

MIL-DTL-83513 Innovations and Advancements

Modern MIL-DTL-83513 connectors leverage advanced materials and design techniques to push the boundaries of performance. Innovations such as enhanced EMI shielding, higher current-carrying capacity, and improved miniaturization continue to expand their usability in cutting-edge defense technologies.
