UAV Stubby Antennas
Apella Solutions' range of omnidirectional stubby antennas provides an excellent RF communications solution for tactical drones and ground robotics and is also suitable for other space-constrained applications.
Available in L, S and C band designs as standard with other frequencies possible upon request, these antennas feature a compact and lightweight build and ensure consistent signal strength for mission-critical platforms operating under highly challenging conditions.
| S-Band | C-Band | |
| Dimensions: | 110 x 20 mm | 60 x 20 mm |
| Weight: | ~30g | |
| Frequency Range: | 1800 – 2300 MHz | 5500 – 6000 MHz |
| Azimuth: | 360o | |
| Gain: | 3dBi +/-1dB | 3 dBi peak |
| VSWR: | 2.5:1 min 2:1 nominal |
2:1 nominal |
| RF Power Handling: | 25W | |
| Connector: | SMA male | |
| Polarization: | Vertical | |
