New Catalog Radiation Tolerant 30 GHz SPDT RF Switch for Space Applications

Teledyne e2v HiRel’s new RF switch, developed on 0.15 μm InGaAs pHEMT technology, will be available as die and is qualified per MIL-PRF-38534 Class K equivalency for use in high reliability, space and defense applications By DA Staff / 27 Jun 2022
HiRel_30GHz_Switch_Die
Follow DA

Teledyne e2v HiRel has announced the availability of a rad-tolerant 30 GHz, Single Pole Double Throw (SPDT) reflective RF switch, model TDSW030A2T, designed for use in demanding high reliability, space and defense applications.

Now available with qualified material off-the-shelf, this new RF switch, developed on 0.15 μm InGaAs pHEMT technology, will be available as die and is qualified per MIL-PRF-38534 Class K equivalency for space applications.

The TDSW030A2T leverages Monolithic Microwave Integrated Circuit (MMIC) design techniques that deliver superior performance in the Ku and Ka microwave and millimeter-wave bands. The switch delivers low insertion loss, high isolation, fast switching times, and high linearity across a wide frequency band from dc to 30 GHz and attains an input power 1 dB compression of 25 dBm (typical). Class K equivalent element evaluation is performed per wafer.

“While switching is one of the core microwave building blocks, there has been a lack of choice for designers working on high-reliability applications,” said Mont Taylor, Vice President and Business Development Manager at Teledyne e2v HiRel. “Joining our successful release of a 20 GHz switch last fall, this new product is the first 30 GHz switch qualified as TID radiation tolerant to 100 krad (Si) on the market.”
