Series 1585 Test Stand
Measure up to 5 kgf of thrust and 2 Nm of torque
The Series 1585 Test Stand is a professional thrust stand for measuring drone propulsion performance, including thrust, torque, voltage, current, RPM, vibration, winding resistance, motor efficiency and propeller efficiency. It connects via USB and uses software for automated control, live data viewing, CSV export and scripted ESC operation.
Designed for UAV developers, the system supports propulsion optimization for quadcopter, multirotor and fixed-wing aircraft. Enhanced dynamic response, greater power capacity and improved electrical noise immunity help refine endurance, payload capability and reliability for defense drone platforms.
| Max Thrust | 5 kgf |
| Max Torque | 1.5 Nm |
| Max Voltage | 50V |
| Max Continuous Current | 55A |
| Max Force Measurement rate | Up to 80 Hz |
