Application Insight: Advanced IR Thermal Imaging Lenses for C-UAS Systems

Enhance threat detection and minimize false positives with Ophir’s high-performance IR continuous zoom lenses for counter unmanned aerial systems Feature Article by Ophir Optronics, an MKS brand
Advanced IR Thermal Imaging Lenses for C-UAS Systems
Follow DA

Ophir Optronics, an MKS brand and a leader in optical solutions, offers cutting-edge IR continuous zoom lenses designed to provide unparalleled performance in Counter-Unmanned Aerial Systems (C-UAS) applications.

These lenses are optimized for long-range detection, precise identification, and reliable tracking of small unmanned aerial systems (sUAS), ensuring superior operational effectiveness in the field.

The rapid proliferation of drones over the past decades has introduced significant security challenges for both civilian and military sectors. This escalation in potential threats has spurred the development of sophisticated C-UAS technologies aimed at detecting, identifying, and neutralizing these risks. Among the leading solutions, infrared (IR) thermal imaging plays a crucial role, especially when integrated into multi-sensor C-UAS platforms.

Ophir’s IR continuous zoom lenses offer advanced optical design and rugged construction making them an asset to modern defense systems tasked with countering the growing threat of sUAS. By providing precise, long-range detection and identification capabilities, these lenses enhance the operational readiness and effectiveness of military and security forces.

Delivering exceptional image clarity with a Modulation Transfer Function (MTF) close to the diffraction limit ensures crisp, clean imagery across the entire zoom range, facilitating accurate identification and tracking. The precision optics maintain focus throughout the full zoom capability, allowing seamless transitions between wide and narrow fields of view without losing sight of the target.

With capabilities extending beyond 8 kilometers, these lenses are engineered for long-range engagements, providing operators with the ability to detect and identify threats from significant distances. This extended reach is crucial for early threat detection and effective countermeasures.

Built to endure the most challenging conditions, Ophir’s lenses are ruggedized and compliant with US and European military standards for temperature, shock, vibration, and environmental sealing.

Features:

  • High-precision optics with MTF close to the diffraction limit
  • Continuous zoom providing adequate, focused pixels on target
  • Focus maintained through the full zoom range/ entire field-of-view range
  • Tight boresight retention
  • Extended identification ranges exceeding 8km
  • Ruggedized design for durability in the harshest environmental conditions
  • Accurate Line-of-Sight (LOS)
  • Focal length ranges from 21mm to 1350mm
  • US and European military standard compliance for temperature, shock, vibration and
  • environmental sealing including DIN 3140, IPC 620, MIL-PRF 13830, Mil-PRF 85285, MIL
  • STD 810, MIL-C-48497, MIL-C-48616, ISO 10110 sections 1-19, ANSI\ASQ Z1.4.
  • Available with high durability (HD) or hard carbon (HC) coatings

To find more information on Ophir’s IR thermal imaging lenses, how they can enhance C-UAS capabilities, and for detailed production specifications download Ophir’s Application Brochure for C-UAS.
