ANELLO IMU+

The ANELLO IMU+ is a rugged inertial measurement unit designed to deliver ultra-reliable performance under the harsh environmental conditions faced by military and defense platforms and vehicles. It has been hardened against a range of stressors including shock, vibration, thermal gradients, moisture, dust, salt spray and chemicals.

The robust unit features the same fault-tolerant triple-redundancy design as the ANELLO X3 IMU with six degrees of freedom, and provides two CAN or serial RS-232 interfaces for easy integration into a wide range of platforms. Data can be output at up to 200 Hz.

Anello IMU inertial measurement unit
Dimensions: 75 x 75 x 28 mm (9.8 in3)
Weight: <1 lbs
Power: 8-30 VDC, 2.5W
Gyro Range: +/- 200°/s
Gyro Bias Instability: < 0.5°/hr
ARW: < 0.05°/√hr
Accel Range: 8g
Accel Bias Instability: 20μg
VRW: 0.03 m/s/√hr
