ANELLO GNSS INS

The ANELLO GNSS INS is designed to provide military vehicles, robotics and armaments with continued high-accuracy navigation performance during jamming and spoofing attacks and other GNSS-denied conditions such as severe multipath and urban canyons.

Based around a dual-antenna RTK-capable GNSS engine paired with ANELLO's revolutionary SiPhOGTM technology and AI-powered sensor fusion, this versatile solution can adapt rapidly to a variety of dynamic mission conditions. It features Ethernet and dual RS-232 interfaces, with position, velocity and attitude outputs at up to 200 Hz.

The rugged unit is IP68-rated and also offers reliable protection against chemicals, salt spray and solar radiation, making it ideal for demanding airborne and ground-based applications.

Anello GNSS INS
Dimensions: 5.8 x 4.3 x 1.3”
Weight: 1 lbs
Power: 8-30 VDC, 4W typical
Gyro Range: 200°/s
Gyro Bias Instability: < 0.5°/hr
ARW: < 0.05°/√hr
Accel Range: 4g
Accel Bias Instability: 20μg
VRW: 0.03 m/s/√hr
Positioning Accuracy: SPS: 1.2 m cep
RTK: 0.02 m cep
60s GNSS Outage: < 1.0 m RMS
Velocity Accuracy: 0.01 m/s RMS
Heading Accuracy: 0.2o RMS
Pitch/Roll Accuracy: 0.02o RMS
GNSS Signals: L1 C/A, L2C, L1OF, L2OF, B1I, B2I, E1, E5b and SBAS
