CRPA Testing Solution for US Air Force

Orolia Defense & Security’s Broadsim Wavefront simulator will be integrated into a test environment for networked, collaborative and autonomous weapon systems being developed under the Golden Horde program By DA Staff / 22 Feb 2022
Orolia CRPA
Follow DA

Orolia Defense & Security has been selected by the U.S. Air Force Guided Weapons Evaluation Facility (GWEF) to deliver the Controlled Reception Pattern Antennas (CRPAs) testing solution.

The company will deliver BroadSim Wavefront, a software-defined CRPA testing system.

The Broadsim Wavefront simulator will be integrated into a test environment for networked, collaborative and autonomous weapon systems being developed under the Golden Horde program. Golden Horde is one of four Air Force Vanguard programs designed to rapidly advance emerging weapons systems and warfighting concepts through prototype and experimentation.

Of the several capabilities the GWEF required, features such as low-latency hardware-in-the-loop, automated calibration, and the flexibility to quickly integrate future signals and sensors were the most critical and serve as a key reason Orolia’s BroadSim Wavefront was selected.

This system will also be capable of testing eight element CRPA systems, eight simultaneous Fixed Radiation Pattern Antenna (FRPA) systems, or a combination of CRPA and FRPA systems.

The GWEF provides laboratory testing and simulation tools for developing precision-guided weapon technology, including a comprehensive scope of GPS/INS systems and integrated components like sensors, signals of opportunity and CRPAs. CRPAs are fundamental in many platforms due to their enhanced protection against electronic attacks in naval warfare environments.

“When designing BroadSim Wavefront, we re-imagined every aspect for the user,” said Tyler Hohman, director of products for Orolia Defense & Security. “Though the GWEF unit contains eight nodes (corresponding to each antenna element), it can be scaled from four to 16 antenna elements. One of the greatest advancements is our continuous phase monitoring and compensation technique. It automatically monitors, aligns and adjusts the phase of each RF output continuously throughout the duration of a scenario.”

“Gone are the days of re-calibrating each frequency on your system, limiting your scenario duration or re-calibration every time you power cycle your system,” added Hohman. “Simply turn the system on, start the scenario, and your Wavefront system phase aligns and remains aligned for the entirety of the test.”

Leveraging the Skydel Simulation Engine, BroadSim Wavefront also supports high-dynamics, MNSA M-Code, alternative RF navigation, open-source IMU plug-in and 1000Hz iteration update rate.

“Because of the software-defined architecture, many upgrades don’t require additional hardware, which has been a crucial advantage for customers who are already using this solution,” Hohman said.
